The Eastern Veil Nebula

The Eastern Veil nebula (also known as Caldwell 33) is a cloud of heated and ionized gas and dust in the constellation of Cygnus and is located at around 1470 light-years from Earth. It is part of the Cygnus Loop which is a faint supernova remnant that exploded aproximately 7000 years ago. From the moment the source star exploded and until now, the Cygnus Loop supernova remnant expanded to a diameter of roughly 3° on the sky (that almost 6 full moons). The red hues in this image are from ionized hydrogen content of gas clouds that emit light in the H-alpha wavelength, while the cyan hues are from oxygen ions.

Image:

Equipment:

  • Nikon D90 (Astro-Mod)
  • Sky-Watcher Star Adventurer
  • Sky-Watcher Tripod
  • AF-S NIKKOR 500mm f/5.6
  • Bahintov Mask
  • Intervalometer
  • Laptop
  • All Sky Plate Solver
  • Sharpcap
  • Stellarium

Acquisition:

  • Taken from a bortle class 2 zone
  • 407 x 1″ light frames – total 6 hours 47 minutes (taken across 2 nights)
  • 59 dark frames
  • 400 flat frames
  • 500 bias frames

Processing:

  • Manually stacked in pixinsight
  • Crop to remove stacking artifacts
  • Image solver
  • DBE
  • Photometric Color Calibration
  • Deconvolution
  • Noise Reduction (TGV + MMT)
  • HSV reparation
  • Masked stretch
  • Star reduction x2
  • Curves with and without masks
  • Sharpening

Annotated Image

2 thoughts on “The Eastern Veil Nebula

  1. Thank you! And yes, I did mean to write 407 X 1′ – I always get confused between the notation for minute and second.

  2. Fantastic image! I would never have thought you could capture the Veil this well with a DSLR and telephoto lens.
    One note, though – you say you captured 407 X 1″ light frames. You must have meant 407 X 1′ (one minute vs. one second), correct?
